Overview

RIOS is a cooperative multitask scheduler written entirely in C that:

• Is simple and understandable for the beginning embedded programmer
• Can provide basic non-preemptive or preemptive cooperative multitasking capabilities for cooperative tasks
• Requires only a few dozen lines of C code. Reduces need for RTOS (real-time operating system).

Versions

• Non-preemptive, simple tasks

#include "RIMS.h"

/*
   Copyright (c) 2013 Frank Vahid, Tony Givargis, and
   Bailey Miller. Univ. of California, Riverside and Irvine.
   RIOS version 1.2
*/
typedef struct task {
   unsigned long period;      // Rate at which the task should tick
   unsigned long elapsedTime; // Time since task's last tick
   void (*TickFct)(void);     // Function to call for task's tick
} task;

task tasks[2];
const unsigned char tasksNum = 2;
const unsigned long tasksPeriodGCD = 200; // Timer tick rate
const unsigned long periodToggle   = 1000;
const unsigned long periodSequence = 200;

void TickFct_Toggle(void);
void TickFct_Sequence(void);

unsigned char TimerFlag = 0;
void TimerISR(void) {
   if (TimerFlag) {
      printf("Timer ticked before task processing done.\n");
   }
   else {
      TimerFlag = 1;
   }
   return;
}

int main(void) {
   // Priority assigned to lower position tasks in array
   unsigned char i = 0;
   tasks[i].period      = periodSequence;
   tasks[i].elapsedTime = tasks[i].period;
   tasks[i].TickFct     = &TickFct_Sequence;
   ++i;
   tasks[i].period      = periodToggle;
   tasks[i].elapsedTime = tasks[i].period;
   tasks[i].TickFct     = &TickFct_Toggle;

   TimerSet(tasksPeriodGCD);
   TimerOn();

   while(1) {
      // Heart of the scheduler code
      for (i=0; i < tasksNum; ++i) {
         if (tasks[i].elapsedTime >= tasks[i].period) { // Ready
            tasks[i].TickFct(); //execute task tick
            tasks[i].elapsedTime = 0;
         }
         tasks[i].elapsedTime += tasksPeriodGCD;
      }
      TimerFlag = 0;
      while (!TimerFlag) {
         Sleep();
      }
   }
}

// Task: Toggle an output
void TickFct_Toggle(void)   {
   static unsigned char init = 1;
   if (init) { // Initialization behavior
      B0 = 0;
      init = 0;
   }
   else { // Normal behavior
      B0 = !B0;
   }
}

 // Task: Sequence a 1 across 3 outputs
void TickFct_Sequence(void) {
   static unsigned char init = 1;
   unsigned char tmp = 0;
   if (init) { // Initialization behavior
      init = 0;
      B2   = 1;
      B3   = 0;
      B4   = 0;
   }
   else { // Normal behavior
      tmp = B4;
      B4  = B3;
      B3  = B2;
      B2  = tmp;
   }
}

• Non-preemptive, state machine tasks

#include "RIMS.h"
/*
   Copyright (c) 2013 Frank Vahid, Tony Givargis, and
   Bailey Miller. Univ. of California, Riverside and Irvine.
   RIOS version 1.2
*/
typedef struct task {
   unsigned long period;      // Rate at which the task should tick
   unsigned long elapsedTime; // Time since task's last tick
   int state;                 //Current state
   int (*TickFct)(int);       // Function to call for task's tick
} task;

enum TG_States { TG_None, TG_s1 };
int TickFct_Toggle(int);

enum SQ_States { SQ_None, SQ_s1, SQ_s2, SQ_s3 };
int TickFct_Sequence(int);

unsigned char TimerFlag = 0;
void TimerISR(void) {
   if (TimerFlag) {
      printf("Timer ticked before task processing done.\n");
}
   else {
      TimerFlag = 1;
   }
   return;
}

int main(void) {
   task tasks[2];
   const unsigned char tasksNum = 2;
   const unsigned long tasksPeriodGCD = 200; // Timer tick rate
   const unsigned long periodToggle   = 1000;
   const unsigned long periodSequence = 200;

   unsigned char i = 0;
   tasks[i].period      = periodToggle;
   tasks[i].elapsedTime = tasks[i].period;
   tasks[i].TickFct     = &TickFct_Toggle;
   tasks[i].state       = TG_None;
   i++ ;
   tasks[i].period      = periodSequence;
   tasks[i].elapsedTime = tasks[i].period;
   tasks[i].TickFct     = &TickFct_Sequence;
   tasks[i].state       = SQ_None;

   TimerSet(tasksPeriodGCD);
   TimerOn();

   while(1) {
      // Heart of the scheduler code
      for (i = 0; i < tasksNum; ++i) {
         if (tasks[i].elapsedTime >= tasks[i].period) { // Ready
            tasks[i].state = tasks[i].TickFct(tasks[i].state);
            tasks[i].elapsedTime = 0;
         }
         tasks[i].elapsedTime += tasksPeriodGCD;
      }
      TimerFlag = 0;
      while (!TimerFlag) {
         Sleep();
      }
   }
   return 0;
}

int TickFct_Toggle(int state) {
   switch(state) { // Transitions
      case TG_None: // Initial transition
         B0 = 0; // Initialization behavior
         state = TG_s1;
         break;
      case TG_s1:
         state = TG_s1;
         break;
      default:
         state = TG_None;
    }
    switch(state) { // State actions
      case TG_s1:
         B0 = !B0;
         break;
      default:
         break;
   }
   return state;
}
int TickFct_Sequence(int state) {
   switch(state) { // Transitions
      case SQ_None: // Initial transition
         state = SQ_s1;
         break;
      case SQ_s1:
         state = SQ_s2;
         break;
      case SQ_s2:
         state = SQ_s3;
         break;
      case SQ_s3:
         state = SQ_s1;
         break;
      default:
         state = SQ_None;
    }
    switch(state) { // State actions
      case SQ_s1:
         B2 = 1;
         B3 = 0;
         B4 = 0;
         break;
      case SQ_s2:
         B2 = 0;
         B3 = 1;
         B4 = 0;
         break;
      case SQ_s3:
         B2 = 0;
         B3 = 0;
         B4 = 1;
         break;
      default:
         break;
   }
   return state;
}

Porting to AVR microcontrollers

For more information on running RIOS on an AVR, check here.

Student Projects

• All projects (unedited)
• Highlights

About

RIOS stands for Riverside/Irvine Operating System, developed at the University of California (UC) Riverside and UC Irvine. RIOS is not really an operating system but rather a simple task scheduler, the key element of a real-time operating system in embedded systems.
